3x2 HDMI Matrix Switch 4K 60Hz 18Gbps Ultra HD with HDCP 2.2, EDID, IR Remote

1. This HDMI 3x2 Matrix Switch allows you to connect three 4K HDR signal sources to two HD displays or monitors simultaneously.
2. It also supports extracting HDMI input audio signals via Toslink SPDIF optical fiber or a 3.5mm stereo headphone output.
3. Control options include an IR remote control and local buttons for easy switching or splitting between two HDMI-compatible monitors or projectors.
4. Key specifications: 3 HDMI inputs and 2 HDMI outputs, black color, DC 5V power supply, max working current 600mA, operating temperature range -15°C to +45°C, dimensions 170x56x24mm, weight 0.25kg.
5. Features: Supports HDMI 2.0b and HDCP 2.2, 3D video format, maximum resolution up to 3840x2160/60Hz, 18.5Gbps data rate, TMDS clock up to 600MHz, deep color 8/10/12/24/32/48bit, simultaneous HDMI audio output with 3.5mm earphone jack and optical output. HDMI resolution supports up to 3840x2160/60Hz at RGB 4:4:4.

Specifications

• Weight: g
• Length: mm
• Width: mm
• Height: mm
