4K HDMI Audio Extractor Splitter, HDMI Input to HDMI Output, Optical TOSLINK SPDIF & 3.5mm Stereo, OZV8-1

1. This 4K HDMI Audio Extractor Splitter allows you to connect one HDMI input source to an HDMI output (pass-through mode) while simultaneously extracting digital and analog audio signals.
2. Audio outputs include Toslink SPDIF (optical) for 2.0CH/5.1CH digital audio and a 3.5mm stereo jack for 2CH analog audio. It ensures high-fidelity, lossless audio and video transmission synchronously.
3. HDMI resolution support: 4K2K@60Hz, 3D, 1080P, 720P, 576P, 480P, and 480i. Video color format supports 24bit, deep color 30bit, and 36bit. Maximum bandwidth: 600MHz; maximum baud rate: 18Gbps.
4. Input and output cable distance: up to 10 meters with AWG26 HDMI standard cable. Maximum working current: 350mA. Requires DC5V power supply (not included).
5. Supports Blu-ray 24/50/60fps, HD media players, and XVYCC. Digital audio formats include DTS-HD, Dolby TrueHD, LPCM7.1, DTS, Dolby AC-3 (note: does not support Dolby Digital Plus).

Specifications

• Weight: 1 g
• Length: 10 mm
• Width: 10 mm
• Height: 10 mm
