4K HDMI Matrix Switch 3x2 with Audio Extractor, 4K@60Hz, HDCP 2.2, HDR10, EDID, SPDIF and 3.5mm L/R, IR Remote

1. Product Type: HDMI Matrix Switch 3x2 with Audio Extractor

2. This device allows you to connect three 4K HDR signal sources to two HD displays or monitors. It can also extract audio from the HDMI input signal, outputting via Toslink SPDIF optical fiber or a 3.5mm stereo headphone jack.

3. Control options include an IR remote control and local buttons, making it easy to switch or split signals to two compatible HDMI monitors or projectors.

4. Key Features:

- Supports HDMI 2.0b and HDCP 2.2

- Supports 3D video format

- Maximum resolution up to 3840x2160 at 60Hz (RGB 4:4:4)

- Data rate up to 18.5Gbps, TMDS clock up to 600MHz

- Supports deep color 8/10/12/24/32/48bit

- Simultaneous audio output via HDMI, 3.5mm jack, and optical output

5. Interface: 3 HDMI Inputs, 2 HDMI Outputs

6. Color: Black

7. Power Supply: DC 5V, max working current 600mA

8. Operating Temperature: -15°C to +45°C

9. Dimensions: 170 x 56 x 24 mm (LxWxH), Weight: 0.25 kg

Specifications

• Weight: g
• Length: mm
• Width: mm
• Height: mm
