4K HDMI Switch and Extractor 4x2 with Optical SPDIF, Coaxial, 3.5mm AUX, ARC, HDR, HDCP 2.2, EDID, 4K@60Hz

1. 4K HDMI Switch 4x2 with Audio Extraction

This HDMI switch splitter allows you to connect 4 HDMI signal sources to 2 HDMI display terminals, such as TVs, monitors, or projectors. It supports 4K@60Hz resolution, HDR, HDCP 2.2, and EDID management for reliable signal switching.

2. Audio Extraction Capabilities

The device can extract audio from the HDMI signal and output it to optical SPDIF (Toslink), coaxial, and 3.5mm AUX ports. You can use these audio outputs simultaneously or separately to connect to an amplifier or sound system, even without a TV or monitor connected.

3. Specifications

- Product Type: HDMI Switch Splitter 4x2

- Interface: 4 x HDMI input, 2 x HDMI output

- Audio Outputs: 3.5mm AUX, Coaxial, Toslink (SPDIF)

- Power Adapter: Input AC 100-240V 50/60Hz, Output DC 5V/2A

- Supports ARC (Audio Return Channel), HDR, and HDCP 2.2

4. Wide Compatibility

This switch works with various devices including computers, media players, smart boxes, Blu-ray players, game consoles, and LCD TVs, monitors, or projectors. It also supports connection to audio/video receivers for enhanced sound.

Specifications

• Weight: 250 g
• Length: 180 mm
• Width: 130 mm
• Height: 30 mm
