HDMI Audio Extractor V1.4 4K Support with Optical Toslink SPDIF and RCA Stereo Audio Splitter

1. This device is an HDMI Audio Extractor that takes one HDMI input and outputs it to one HDMI plus audio.
2. It supports Optical Toslink SPDIF and RCA L/R Stereo Analog audio outputs, allowing you to extract audio from your HDMI source.
3. The HDMI to HDMI audio converter provides synchronous separation of video and audio signals without signal loss.
4. Three audio mode options are available: PASS, 2.0CH, and 5.1CH.
5. It supports various audio formats including DTS-HD, Dolby TrueHD, LPCM 7.1, DTS, Dolby AC3, and DSD.
6. Specifications: 1 HDMI input, 1 HDMI output, L/R audio port, Toslink SPDIF optical port. Maximum bandwidth: 340MHz, maximum baud rate: 10.2 Gbps. HDMI resolution supports 4K@30Hz, 3D, 1080p, 1080i, 720p, 576p, 576i, 480p, and 480i.
7. Compatible source devices include game consoles, media players, streaming devices, desktop computers, and laptops. Output can be connected to full HD TVs, monitors, projectors, speakers, amplifiers, soundbars, or other sound systems.

Specifications

• Weight: 80 g
• Length: 150 mm
• Width: 80 mm
• Height: 20 mm
