HDMI Splitter 1x2 with Audio Extractor, 4K Dual Monitor Adapter, HDCP 2.2

1. HDMI Splitter 1x2 with Audio Extractor: Distributes 1 HDMI source to 2 HDMI displays simultaneously, with an additional L+R audio output port.

2. Compatibility: Supports HDCP 2.2 and HDMI 2.0b. Input compatible with computers, laptops, game consoles, media players. Output compatible with projectors, HDTVs, screens, monitors, DVI/DP monitors.

3. Specifications:

- Interface: 1 HDMI input, 2 HDMI outputs, 1 Audio R/L output

- Power: DC 5V

- Dimensions (LxWxH): 52.2 x 58.4 x 15mm

- Supports HDMI 2.0b, HDCP 2.2, HDR10, 18.5Gbps, 4K HDR

- Supports 4K x 2K@60Hz, RGB 8:8:8, 3D

- Supports Blu-ray 24/50/60fps, HD media players, XVYCC

- TMDS signal: 5-1.5 volts p-p (TTL)

- HDMI resolutions: 4K/2K/3D/1080p/1080i/720p/480p

- Video color format: 24/30/36-bit deep color

- Digital audio format: DST-HD, Dolby TrueHD, LPCM 7.1, DTS, Dolby AC3, DSD (Note: Always Dolby Digital plus not supported)

- Input/Output cable distance: <8m AWG26

4. Package includes: 1x HDMI Splitter with Audio Extractor (power adapter not shown, but required DC 5V).

Specifications

• Weight: 370 g
• Length: mm
• Width: mm
• Height: mm
